Bulk Solids Flow Meter – DYNAchute MF 7000 Chute Weigher

Model:

MODEL	Bulk Solids Flow Meter - DYNAchute Chute Weigher
Measurement Range	1–50 t/h
Measuring Principle	Gravimetric weighing + non-contact velocity measurement
Installation	Vertical free-fall
Housing Material	Stainless Steel 1.4301
Protection Rating	IP66
Pressure	±0.1 bar
Supply Voltage	18–36 VDC (galvanically isolated)
Power Consumption	3.5 W
Cable Glands	M20 × 1.5 (Ø6–12 mm cable)
Process Temperature	-10°C to +40°C
Ambient Temperature	0°C to +50°C
Storage Temperature	0°C to +60°C

MUTEC DYNAguard D Eco FlowSwitch FS 710 Dust monitoring and filter break detection

Model:

Model	MUTEC FlowSwitch FS 710 Dust Monitor
Measuring Principle	Triboelectric
Application	Dust Monitoring & Filter Break Detection
Installation Position	Clean Air Side of Bag or Cartridge Filters
Process Temperature	-20°C to +150°C (Up to +180°C for ATEX version)
Process Pressure	0–2 bar
Power Supply	24 VDC
Output	2 × Relay Contacts (Pre-Alarm & Main Alarm)
Protection Class	IP65
ATEX Certification	Optional, up to Zone 20/21

FlowSwitch DYNAguard GM – FS 780 Triboelectric Dust Monitor

Model: FS510M-1-1-2

Model	Mutec DYNAGuard GM FlowSwitch FS 780
Measuring Principle	Triboelectric dust monitoring
Application	Filter break detection for bag filters and cartridge filters
Output	Relay or 4–20 mA analog output
Rod Length	45–800 mm, customizable
Process Temperature	−20°C to +90°C (optional 130°C, 200°C, or 290°C versions)
Process Pressure	0–6 bar
Protection Class	IP67
Optional Features	ATEX Zone 2 / Zone 22, food industry version available

MUTEC FS 550 Microwave Flow Switch Bulk Solids

Model:

Model	MUTEC Microwave Flow Switch FS 550 with Trend measurement
Measuring technology	Microwave
Measurement type	Contactless trend measurement
Installation distance	Several meters
Supply voltage	24 VDC (18–30 VDC)
Analog output	4–20 mA
Housing	Stainless steel
Protection rating	IP65
Process temperature	-20 °C to +85 °C
Standard process pressure	6 bar
Optional pressure version	30–60 bar
Sensor surface	Teflon (ceramic optional)

Solids Flow Switch for Flexible Hoses – MUTEC DYNAguard S FS 620

Model:

Specification	Value
MODEL	MUTEC DYNAguard S FS 620 - Flow switch for bulk solids in flexible hoses
Measurement Principle	Electrostatic (Contactless)
Application	Flexible Hose Flow Monitoring
Sensitivity	0.1 mg/m³
Output	Relay, Transistor or 4–20 mA
Operating Pressure	Up to 10 bar (140 psi)
Operating Temperature	Up to +70°C (158°F)
Protection Rating	IP67
Hazardous Area	Optional ATEX Zone 2 / 22

Continuous Flow Monitor for Bulk Solids- MUTEC Flow Switch FS 600

Model:

Specification	Value
Model	MUTEC Flow Switch FS 600 - Continuous flow monitoring for bulk solids in small pipelines
Measuring principle	Electrostatic / Extended triboelectric
Pipe diameter	10–100 mm
Housing material	Stainless steel (1.4305)
Process coupling	Stainless steel (1.4571)
Ambient temperature	-20°C to +70°C
Process temperature	-20°C to +90°C
Process pressure	Up to 40 bar
Protection class	IP67
Power supply	17–31 VDC
Current consumption	60–90 mA
Output options	Relay, Transistor or 4–20 mA
Hazardous area option	ATEX Zone 20 or Zone 2 (optional)

Solids Flow Meter – DYNAmas MF 5000 Capacitive Mass Flow Measurement

Model:

MODEL	DYNAmass MF 5000 - Solids Flow Meter
Accuracy typically	1 - 3 %
Process temperature	standard: max. 130°C (266°F)
Prozess pressure	max. 64 bar (900 lbs)
Ambient cond. temperature	-40°C...+60°C (-40°F...140°F)
Ambient cond. protection class	IP 68 (EN 60529)
Ambient cond. interference immunity	according to EN 61326-1
Parametrierung via CAN-Bus	through DYNAcon / Notebook
Output via CAN-Bus	through DYNAcon: Mass flow rate, concentration, Velocity, failure, simulation value, limits status
CAN-Bus transmission rate	40 kBaud cable length max. 1000 m
Supply voltage	19...31 V DC, max. 10 W
Damping	1-30 s, fast adaptation to rapid change of the value

Microwave flow switch – Mutec FS510M Microwave material flow monitoring

Model: FS510M-2

Specification	Value
Housing Material	Stainless Steel
Sensor Surface	Teflon (Optional Ceramic)
Protection Rating	IP65
Operating Temperature	Ambient: -20°C to +60°C; Process: -20°C to +80°C
Maximum Process Pressure	2 bar (Optional 25 bar)
Power Supply	24 VDC (18–30 VDC)
Output Signal	Potential-Free Relay Contact
Adjustable Parameters	Sensitivity, Damping, Filter, Hysteresis, Min./Max. Switching

Solids Velocity Meter – DYNAvel Velocity measurement

Model: FS510M-1-2-1-1

Parameter	Specification
Measuring Principle	Non-contact solids velocity measurement
Measurement Method	Absolute transit time measurement
Measurement Type	Continuous online velocity measurement
Suitable Applications	Pneumatic conveying and free-fall processes
Measured Materials	Powders, dust, pellets, granules, and bulk solids
Analog Output	4–20 mA
Communication	CAN-Bus
Maintenance	Maintenance-free operation
Calibration	No calibration required
System Integration	PLC, SCADA, and DYNAcon compatible

Inline particle size analyzer – PA 3000 continuous particle size measurement

Model:

Parameter	Specification
Measuring Principle	Optical inline particle size measurement
Measuring Range	170–6,000 µm
Measurement Speed	Up to 10,000 particles per second
Communication Interface	RS485
Alarm Output	Programmable relay outputs
Enclosure Rating	IP65
Process Temperature	-10°C to +60°C (14°F to 140°F)
Hazardous Area Certification	ATEX Zone 2/22 (optional)

Dust Sensor for Monitoring the Ambient Air – DYNAairguard

Model:

Parameter	Specification
Supply (versions with switching output)	24 VDC
Supply (versions with analogue output)	24 VDC
Output (versions with relay switching output)	Max. 48 VAC/DC, 1 A; NC (normally open) / NO (normally closed) selectable
Output (versions with analogue output)	4–20 mA (active), galvanically isolated, Load < 500 Ω
Sensitivity	From 0.1 mg/m³
Damping	0–10 s
Switching Point (versions with switching output)	Adjustable from 1 to 10
Comparison (versions with analogue output)	4 mA = Zero level
Ambient Temperature	-20 °C to +50 °C (-4 °F to 122 °F)
Flow Rate	Approx. 100 m³/h
Noise Development	29 dB(A)
Material – Flow Channel	Painted steel
Material – Electronics Housing	Stainless Steel 1.4301
Material – Sensor Rod	Stainless Steel 1.4571
Sensor Rod Insulation	PA
Seal Material	FPM
Degree of Protection	IP20 (EN 60529)
Electromagnetic Compatibility (EMC)	According to EN 61326-1
Weight	5 kg

Microwave barrier and contactless level monitoring of bulk materials – MUTEC LevelCheck LC 510

Model:

Technical Specifications

Parameter	Specification
Measuring Technology	Contactless Microwave Barrier
Supply Voltage	18–30 VDC (24 VDC nominal)
Current Consumption	Approx. 80 mA
Relay Output	1 × Potential-free changeover relay, 1 × READY relay
Housing Material	Stainless Steel
Sensor Surface	Teflon (optional Ceramic for abrasive applications)
Protection Class	IP65
Ambient Temperature	-10°C to +70°C*
Process Temperature	-20°C to +90°C*
Process Pressure	0.8–1.1 bar standard (higher pressure versions available)
Maximum Detection Distance	Up to 25 m
ATEX Version	Optional, suitable for Zone 21 and Zone 20 with AD510 adapter

Solids Mass Flow Meter – MUTEC DYNArad MF 9000

Model:

Technical Specifications

Specification	DYNArad MF 9000
Product Name	DYNArad MF 9000 Mass Flow Meter
Measurement Method	DYNAvel electrostatic velocity measurement + radiometric density measurement
Velocity Range	Approx. 0.5–100 m/s*
Concentration Range	Dilute phase to dense phase conveying
Flow Range	Up to 500 t/h*
Pipe Size	DN100–DN400
Operating Pressure	Up to 64 bar
Protection Class	IP67
Accuracy	Up to ±1% (application dependent)
Housing	Rugged industrial housing for harsh environments
Installation	Pneumatic conveying pipelines and vertical free-fall systems

Mutec MF 3000 Bulk Solids Mass Flow Meter

Model:

Parameter	Specification
Measurement start (Free-fall)	From approximately 20 kg/h
Measurement start (Pneumatic conveying)	From approximately 1 kg/h
Maximum pipe diameter	Up to DN 300 (12")
Particle size	Approximately 1 nm to 20 mm
Material moisture	Suitable for dry bulk materials with varying moisture content
Process pressure	Standard 6 bar, temporary up to 30 bar
Process temperature	Standard -20°C to +90°C, optional versions up to +450°C
Construction	Wall-mounted industrial transmitter
Auxiliary power	100–240 VAC, 50/60 Hz (optional versions available)
Power consumption	Approximately 20 VA
Ambient temperature	-20°C to +60°C
Protection class	IP65

Inline moisture measurement Mutec DYNAmoist – Humy 301

Model:

MODEL	In-line moisture measurement MUTEC HUMY 301
Measuring Range	0–85% Residual Moisture or 15–100% Dry Matter (TR)
Accuracy	Up to ±0.1% (material dependent)
Power Supply	24 VDC
Power Consumption	Max. 1.5 W
Operating Pressure	6 bar (10 bar temporary)
Protection Rating	IP67
Ambient Temperature	0 to +70°C or +80°C (depending on version)
Process Temperature	Up to +120°C (High Temperature Option, Non-ATEX)
Communication	RS485 Modbus

ĐO KÍCH THƯỚC HẠT TRỰC TUYẾN (IN-LINE) THEO THỜI GIAN THỰC – DYNAsize/ PA 3000

Model:

Dải kích thước hạt	170 - 6,000 µm
Tốc độ đo	Lên tới 10,000 hạt/giây
Kích thước đường ống	DN200, DN250, DN300 (Kết nối mặt bích)
Nhiệt độ quy trình	-10°C đến +60°C
Áp suất quy trình	Tối đa 6 bar
Cấp bảo vệ	IP 65

CẢM BIẾN ĐO NỒNG ĐỘ BỤI ĐỂ GIÁM SÁT KHÔNG KHÍ XUNG QUANH (Dust sensor for monitoring the ambient air) – DYNAairguard – DS 300

Model:

Nguồn cấp: 24 VDC.
Độ nhạy: Từ 0.1 mg/m³
Nhiệt độ môi trường: -20℃ đến 50℃.
Vật liệu vỏ điện tử: Thép không gỉ (Stainless steel 1.4301).
Vật liệu thanh cảm biến: Thép không gỉ (Stainless steel 1.4571).
Vật liệu ống dẫn khí: Thép sơn tĩnh điện.
Cấp bảo vệ: IP20 (theo tiêu chuẩn EN 60529).

ĐỒNG HỒ ĐO LƯU LƯỢNG KHỐI LƯỢNG LỚN (Speed Measurement of bulk solids and powder) DYNArad – MF9000

Model:

Model: MF9000 (Speed Measurement of bulk solids and powder) – Dòng thiết bị đo chuyên dụng cho lưu lượng khối lượng lớn.
Phương pháp đo: Sử dụng công nghệ không tiếp xúc (Non-contact) và không xâm lấn (Non-intrusive), đo xuyên qua thành ống mà không chạm vào vật liệu.
Ứng dụng đa năng: Hoạt động hiệu quả trên cả hệ thống băng tải khí nén (Pneumatic conveyors) và các đường ống rơi tự do (Free-fall).
Vật liệu đo: Tương thích với đa dạng nguyên liệu rời như bột, hạt, viên nén, khoáng sản, than đá, xi măng...

Cảm Biến Đo Lưu Lượng Chất Rắn Mutec (DYNAmflow – MF 3000, DYNAmas – MF 5000, DYNAchute – MF 7000)

Model:

Nguyên lý đo: Điện dung (Capacitive) kết hợp đo vận tốc thời gian thực.
Dải lưu lượng: Rất rộng, từ lượng nhỏ (0.1 kg/h hoặc 50 kg/h) lên đến hơn 400 - 500 tấn/giờ.
Kích thước đường ống: 10 kích thước từ DN25 đến DN300 (1 inch đến 12 inch).
Độ chính xác: Điển hình từ 1% đến 4%.
Môi trường ứng dụng:
Vận chuyển khí động (cả pha loãng và pha đặc/dense phase).
Rơi tự do.
Có thể lắp đặt ở đường ống đứng, ngang hoặc nghiêng.
Tiêu chuẩn an toàn: Đạt chuẩn phòng nổ EX zone 20 hoặc 1.

Đo Lưu Lượng Khối Lượng Cho Nguyên Liệu Rời (Hạt/Bột) (Microwave mass flow measurement) – Mutec Model MF3000

Model:

Công nghệ Vi sóng (Microwave)
Giám sát thời gian thực
Loại trừ nhiễu
Thiết kế tối ưu
Không cần bảo trì
An toàn phòng nổ (ATEX)

Cảm Biến Báo Mức Mutec LevelCheck LC 510

Model:

Vật liệu vỏ: Thép không gỉ 1.4307 (Inox 304L), chống ăn mòn.
Bề mặt cảm biến: Teflon (Tiêu chuẩn) hoặc Gốm (Tùy chọn chịu nhiệt/mài mòn).
Kết nối cơ khí: Ren G 1 ½ inch.
Khoảng cách đo: Tối đa 25 mét.
Nhiệt độ quy trình: -20°C đến +85°C.
Áp suất quy trình: Tiêu chuẩn 6 bar (Tùy chọn phiên bản chịu áp cao 30-60 bar).
Nguồn cấp: 24 VDC (18-30 VDC).
