Accurate point level detection is essential for maintaining stable production, preventing overfilling, and ensuring a continuous material supply in bulk solids handling systems. The Mutec LC510 Microwave Level Check uses contactless microwave barrier technology to detect material presence without coming into contact with the process, making it suitable for applications where dust, steam, or material buildup can reduce the reliability of conventional sensors.
The system consists of a microwave transmitter and receiver installed opposite each other. When bulk material interrupts the microwave beam, the receiver changes its relay output to indicate either a maximum (MAX) or minimum (MIN) level, depending on the configured operating mode. This measurement principle provides stable switching performance while eliminating mechanical wear and minimizing maintenance requirements.
Designed for industrial environments, the LC510 can be installed on silos, storage bunkers, crushers, hoppers, chutes, pipelines, conveyors, and process containers. With adjustable operating parameters, measuring distances of up to 25 meters, active self-monitoring, and optional ATEX versions for hazardous areas, the LC510 offers a reliable solution for contactless point level monitoring across a wide range of bulk material applications.
How the Mutec LC510 Microwave Level Check Works
The LC510 detects point levels by transmitting a microwave signal between a transmitter and receiver. When bulk material interrupts this signal, the receiver immediately changes its relay output to indicate either a high-level or low-level condition.
Explore other Mütec process measurement solutions: Bulk Solids Measurement Products
Contactless Microwave Measurement Principle
The LC510 uses two independent microwave sensors: a microwave sender (transmitter) and a microwave receiver. These two devices are mounted directly opposite each other, creating a microwave barrier across the measuring point.
During normal operation, the transmitter continuously emits a low-power microwave signal toward the receiver. As long as the microwave beam reaches the receiver without obstruction, the system recognizes that the measuring path is clear. When bulk material enters the detection zone and blocks the microwave transmission, the receiver identifies the interruption and processes it through its internal evaluation electronics. The configured relay output then changes state to provide a switching signal for the control system.
Unlike mechanical level switches, the LC510 never touches the product being monitored. This non-contact measurement principle eliminates mechanical wear and allows continuous operation without the moving parts typically found in conventional level detection devices. It also helps maintain stable performance in dusty or steam-filled environments where optical sensors or mechanical devices may be affected.
Another advantage of the system is its straightforward installation. The transmitter and receiver operate as two separate units and do not require a direct electrical connection between each other. Each sensor is installed independently, simplifying wiring and commissioning while maintaining reliable signal transmission across measuring distances of up to 25 meters, depending on the application.
Level Detection Modes
The LC510 supports both maximum level detection (MAX) and minimum level detection (MIN), allowing it to adapt to different process requirements.
In MAX level monitoring, the microwave path remains unobstructed while the vessel is filling. Once the material reaches the preset level and blocks the microwave beam, the receiver switches its relay output to indicate that the maximum level has been reached. This function is commonly used to prevent overfilling of silos, storage bins and process containers.
In MIN level monitoring, the operating logic is reversed. After material is discharged from the vessel and the microwave path becomes clear again, the receiver changes its output state to indicate that the minimum material level has been reached. This helps maintain continuous material supply and prevents equipment from operating without sufficient product.
The LC510 provides relay outputs for integration with PLCs, alarms and other industrial control systems. In addition to the process relay, the receiver incorporates an independent READY relay for active self-monitoring. Under normal operating conditions, this relay remains energized. If the system detects an internal fault or maintenance condition, the READY relay changes state, allowing maintenance personnel to identify potential issues before they affect process reliability.
This combination of contactless microwave detection, configurable switching logic and continuous self-monitoring enables the LC510 to provide stable point level detection for a wide variety of bulk material handling applications.
Features and Typical Applications
The LC510 combines contactless microwave measurement with a robust industrial design, providing reliable point level detection across a wide range of bulk material handling applications.
Related Mütec Measurement Solutions
If your process requires additional process monitoring beyond point level detection, you may also be interested in: DYNArad MF 9000 – Continuous microwave mass flow measurement for pneumatic conveying systems
Main Features
The LC510 is designed to deliver stable switching performance while minimizing maintenance and installation complexity. Its microwave barrier technology eliminates direct contact with the process material, allowing the sensor to operate reliably even in demanding industrial environments.
- Contactless measurement – Detects the presence of material without physical contact, eliminating wear caused by friction or product impact.
- Reliable microwave technology – Uses a stable microwave beam to provide consistent point level detection for both bulk solids and selected liquid applications.
- Wear-free operation – No moving mechanical components are exposed to the process, helping maintain long-term measurement stability.
- Maintenance-free design – The non-contact measuring principle significantly reduces routine maintenance requirements under normal operating conditions.
- Stainless steel housing – Rugged stainless steel construction provides excellent durability for industrial installations, while an optional ceramic sensor surface is available for abrasive materials.
- Active self-monitoring – An integrated READY relay continuously monitors the operating status of the sensor and can report maintenance requirements or internal faults.
- Relay output – Potential-free relay contacts allow straightforward integration with PLCs, alarm systems and process control equipment.
- Adjustable operating parameters – Users can configure amplification, filter time, hysteresis, switching delay and MAX/MIN operating mode directly on the device to match different process conditions.
- Simple installation – The transmitter and receiver are installed independently using threaded process connections, making commissioning fast and uncomplicated.
- Measuring distance up to 25 meters – Depending on the application, the transmitter and receiver can be installed up to 25 m apart while maintaining reliable signal transmission.
- Optional ATEX version – Explosion-protected models are available for hazardous dust environments, with support for Zone 21 and Zone 20 applications when used together with the AD510 adapter.
Typical Applications
The LC510 is suitable for point level detection wherever reliable material presence monitoring is required. Because microwave measurement is unaffected by dust, steam or product buildup, the sensor can be installed in a variety of bulk material handling systems.
Equipment
Typical installation locations include:
- Silos
- Storage bunkers
- Crushers
- Containers
- Conveyors
- Pipes
- Chutes
In addition to level monitoring, the microwave barrier can also be used to detect material passage, monitor product flow through transfer points and identify object movement in industrial processes.
Industries
The LC510 is widely applied across industries that handle powders, granules and other bulk materials, including:
- Cement and building materials
- Chemical processing
- Food manufacturing
- Animal feed production
- Mining and mineral processing
- Power generation
- Recycling facilities
- Pharmaceutical manufacturing
- Glass production
- Ceramics
- Paper and pulp
- Textile production
- Pigment manufacturing
- Waste incineration plants
Its versatile design allows the same measuring principle to be used across multiple industrial sectors while maintaining consistent switching performance under varying process conditions.
Technical Specifications and Installation
The LC510 combines industrial-grade hardware with straightforward installation, making it suitable for both new process installations and equipment upgrades.
Looking for a Complete Bulk Solids Measurement System?
LC510 is commonly installed together with other Mütec instruments for comprehensive process monitoring.
Continuous Mass Flow Measurement MF 3000
Technical Specifications
| Parameter |
Specification |
| Measuring Technology |
Contactless Microwave Barrier |
| Supply Voltage |
18–30 VDC (24 VDC nominal) |
| Current Consumption |
Approx. 80 mA |
| Relay Output |
1 × Potential-free changeover relay, 1 × READY relay |
| Housing Material |
Stainless Steel |
| Sensor Surface |
Teflon (optional Ceramic for abrasive applications) |
| Protection Class |
IP65 |
| Ambient Temperature |
-10°C to +70°C* |
| Process Temperature |
-20°C to +90°C* |
| Process Pressure |
0.8–1.1 bar standard (higher pressure versions available) |
| Maximum Detection Distance |
Up to 25 m |
| ATEX Version |
Optional, suitable for Zone 21 and Zone 20 with AD510 adapter |
*The operating manual specifies an ambient temperature range of -10°C to +70°C and a process temperature range of -20°C to +90°C for the standard operating conditions, while the product datasheet provides general specifications for standard models. Always confirm the applicable limits for the selected model before installation.
Installation Requirements
Proper installation is essential to achieve stable microwave transmission and reliable switching performance.
The microwave sender and receiver should be mounted directly opposite each other so that the microwave beam passes through the intended detection zone. Both sensors are installed using a threaded process connection and secured with a lock nut to ensure accurate alignment.
For safe operation, the sensor housing should be correctly grounded through the protective earth (PE) connection, while power supply and relay wiring should follow the manufacturer’s terminal assignment and electrical recommendations. Separating the 24 VDC supply wiring from relay circuits also helps minimize electromagnetic interference during operation.
For hazardous dust environments, the LC510 is available with an ATEX version. When measurements are required in Zone 20, the AD510 adapter must be installed in accordance with the manufacturer’s installation requirements.
To support different installation conditions, Mütec also provides mounting accessories including weld-in adapters, threaded sockets and dedicated mounting components, allowing the LC510 to be integrated into silos, pipelines, process vessels and other industrial equipment with minimal modification.
Configuration, Operation and Maintenance
The LC510 allows key operating parameters to be configured directly on the device, enabling the sensor to be optimized for different process conditions while maintaining reliable long-term operation with minimal maintenance.
Adjustable Parameters
The LC510 is configured using rotary switches, push buttons and potentiometers located inside the sensor housing. A multi-color LED bar graph provides visual feedback during commissioning, allowing operators to monitor signal strength and parameter settings without additional software.
Signal Gain
Signal Gain adjusts the microwave field strength to match the installation and material characteristics. Proper gain adjustment ensures that the receiver can clearly distinguish between an unobstructed microwave path and the presence of bulk material, resulting in stable switching performance.
Filter Time
The filter function averages the received microwave signal over a selected period before processing the switching output. Increasing the filter time helps suppress short-term signal fluctuations caused by unstable material flow, while shorter filter settings provide a faster response for dynamic processes.
Hysteresis
Hysteresis defines the switching tolerance around the selected threshold. An appropriate hysteresis value prevents unnecessary relay switching caused by minor fluctuations in signal strength while maintaining reliable detection of genuine level changes.
Switching Delay
The switching delay determines how long the microwave signal condition must remain stable before the relay changes state. This parameter helps eliminate unwanted switching caused by temporary disturbances or pulsating material flow and can be adjusted to suit different process requirements.
MAX / MIN Mode
The LC510 supports both maximum level and minimum level monitoring. Users can configure the relay logic according to the application, allowing the same device to be used either for overfill protection or low-level detection without additional hardware modifications.
RESET Function
If required, all operating parameters can be restored to their factory default settings using the RESET function. After resetting, the sensor should be recommissioned and all operating parameters configured again to match the installation conditions.
Maintenance
The LC510 is designed for continuous industrial operation with minimal routine maintenance. Because the microwave measurement is completely contactless, there are no moving mechanical components exposed to the process material during normal operation.
Maintenance-free Operation
Under normal operating conditions, the LC510 requires very little maintenance. The contactless measuring principle minimizes component wear while reducing downtime associated with routine servicing.
READY Relay
The receiver incorporates an independent READY relay that continuously monitors the health of the system. During normal operation the relay remains in its operating state. If an internal fault or maintenance condition is detected, the READY relay changes status so that operators can respond before process reliability is affected.
Self-monitoring
Built-in self-monitoring continuously checks the operating condition of the microwave electronics. This additional diagnostic function improves system availability and provides early warning of abnormal operating conditions.
Inspection for Abrasive Applications
For installations involving highly abrasive materials, the manufacturer recommends periodic inspection of the sensor surface and mounting area. Although the microwave measurement itself is contact-free, prolonged exposure to abrasive product flow may gradually affect exposed mechanical components depending on the installation method.
Visual Inspection Recommendations
Routine visual inspection of the sensor housing, cable connections, mounting hardware and grounding is recommended during scheduled maintenance. Confirming that the transmitter and receiver remain properly aligned also helps maintain reliable long-term measurement performance.
